Harley-Davidson FLS/FXS Evolution 1984-1999
Models Covered:
- FLST 1986-1990
- FLSTC 1987-1993, 1993 HDI, 1994-1999
- FLSTF 1990-1993, 1993 HDI, 1997-1999
- FLSTN 1993, 1993 HDI, 1994-1996
- FLSTS 1993, 1997-1999
- FXST 1984-1990, 1999
- FXSTB 1999
- FXSTC 1985-1999
- FXSTF 1993-1996
- FXSTS 1988-1999
- FXSTSB 1995-1998
Each Clymer repair manual provides step-by-step procedures based upon the complete disassembly of the machine. This hands-on experience combined with extensive research results in a manual that is both user-friendly and detailed. Hundreds of original photos and illustrations guide the reader through every job.
Inside Each Manual:
CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP Maintenance intervals / Engine oil / Control lever lubrication / Drive belt deflection and adjustment / Engine mounts and stabilizer / Tune-up / Engine rotation / Air filter / Compression test / Ignition timing / Valve clearance / Secondary camshaft chain tensioner / Spark plugs
CHAPTER FOUR / ENGINE TOP END AND EXHAUST SYSTEM Cylinder head covers / Camshafts and drive gear / Cylinder head / Valve tappets and shims / Valves and components
CHAPTER FIVE / ENGINE LOWER END Removal and installation / Oil pan and oil pickup strainer / Oil pump / Oil cooler / Oil filter mount / Crankcase / Piston and connecting rod / Piston and rings / Connecting rod / Balance shaft / Crankshaft / Break-in
CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM External shift mechanism / Clutch cover / Clutch master cylinder / Clutch release cylinder / Hose replacement / Clutch flushing / Clutch bleeding
CHAPTER SEVEN / TRANSMISSION AND INTERNAL GEARSHIFT MECHANISM Bearing replacement / Output flange / Internal shift mechanism
CHAPTER EIGHT / FUEL AND EMISSION CONTROL SYSTEMS Air filter housing / Electronic fuel injection (EFI) / Depressurizing the system / Throttle body / Fuel rail and fuel injectors / Throttle and idle cables / Fuel tank / Fuel module (filters and fuel pump) / Fuel pressure test / Evaporative emission control system
CHAPTER NINE / ELECTRICAL SYSTEM Battery / Voltage regulator / Alternator rotor and stator / Ignition system / Starter / Solenoid / Relay / Lighting / Instrument cluster / Speedometer, tachometer and indicator panel / Vehicle speed sensor (VSS) / Turn signal module, turn signal security module and hands-free security module / Horn / Switches / Fuses / Handlebar wiring replacement / Wiring diagrams
CHAPTER TEN / COOLING SYSTEM Coolant pipes / Reserve tank / Radiator and oil cooler / Cooling fans / Oil cooler oil line fittings / Oil cooler / Thermostat and housing / Water pump
CHAPTER ELEVEN / WHEELS, TIRES AND DRIVE BELT Front and rear wheel / Hubs / Driven sprocket / Drive sprocket / Drive belt / Inspection / Wheel truing / Tire changing / Vehicle alignment
CHAPTER TWELVE / FRONT SUSPENSION AND STEERING Handlebar / Front fork / Fork lock / Steering head and stem / Steering head bearing races
CHAPTER THIRTEEN / REAR SUSPENSION Shock absorbers / Swing arm
CHAPTER FOURTEEN / BRAKES Front and rear brake pads / Front and rear brake caliper / Front and rear master cylinder / Brake line replacement / Brake disc / Brake bleeding / Brake pedal
CHAPTER FIFTEEN / BODY AND FRAME Rider seat / Passenger seat / Frame side covers / Air filter housing cover / Front fender / Rear fender / Drive belt and debris deflector covers / Radiator cover / Foot rests / Jiffystand / Windshield / Wind deflector
COLOR WIRING DIAGRAMS
Whether you’re interested in routine maintenance tasks, troubleshooting, or more extensive repairs, the in-depth coverage provides indispensable information about your motorcycle.
This service manual provides service, repair and maintenance information for 1984-1999 Harley-Davidson Softail Big-Twin Evolution FXST, 1984-1999 Harley-Davidson Softail Big-Twin Evolution FXSTC, 1984-1999 Harley-Davidson Softail Big-Twin Evolution FXSTS, 1984-1999 Harley-Davidson Softail Big-Twin Evolution FLST, 1984-1999 Harley-Davidson Softail Big-Twin Evolution FLSTC and 1984-1999 Harley-Davidson Softail Big-Twin Evolution FLSTF models.
Includes everything you need to know to perform tune-up and routine maintenance on the engine, clutch and transmission, fuel and exhaust, ignition system, steering and suspension, wheels, brakes and tires, electrical system, frame and body. Features complete wiring diagrams and 552 illustrated pages.
